Grossing Table
These surgical pathology work stations are useful for examining surgical specimens. The contaminated air & formalin vapours from work table is sucked out by built-in blowers. Provided with lighting system, swivelled-magnifier, SS Table, Sink & Hot & Cold Mixer Top, Metric Rulers-2 Nos. shelf, drawer and storage compartment ,Towel Ring/Tissue Paper Stand and Waste Bin, Magnetic Tool Bar, Tea Stainer.
The working area sides are made from door acrylic material. Widely used, as it is very convenient for "Grossing Work in Histopathology
Fume removal is quiet, efficient and measures less than 65 decibels. Wheel chair accessible design. Installation is quick and easy.
| Optical system | Infinite optical system |
|---|---|
| Illumination | S-LED, 60,000 hrs, 100W Koehler Illumination LED Intensity level display, FLY eye lenses preset switch |
| Viewing Head | Ergonomic Sidentopf Binocular/Trinocular Head, Inclined 30° Rotatable 360° with IPD 52-76mm with a beam Splitter for 100:00/, 50/50, ratio for observation documentation |
| Mechanical Stage | Rackless & Refocusing, Right hand control, hard coated, double slide holder 75×50mm movement |
| Objectives | JAPANESE Infinity Plan/FLOTAR Objectives |
| Condenser | Abbe N.A. 1.25 with universal five position |
| Nosepiece | Quintuple nosepiece with slots for POL |
| Eyepiece | Extra wide field WF 10X with FOV upto 22mm |
| Focusing | Feather Touch Ultra Precise 0.02m per Revolution 2 Stage Coarse, Fine & Tension Adjustment |
| Microscopy Techniques | Polarizing, Darkfield, Fluorescence |
| Certification | CE, UL, ISO |
| Model | Grossing Table | Grossing Table |
| Eyepiece | 1 Pair High eye point wide field plan eyepiece PL10X/20mm | |
|---|---|---|
| Objectives | Infinity Plan Achromatic Objective 2X, 4X,10X, 20X,40X(SL), 60X(SL)& 100x(SL) Oil | |
| Infinity Plan S-APO Objective 2X, 4X,10X, 20X,40X(SL), 60X(SL)& 100x(SL) Oil | ||
| Infinity Plan Fluotar Objective 4X,10X, 20X,40X(SL), 60X(SL)& 100x(SL) Oil | ||
| Infinity Plan Phase Achromatic Objective 10X, 20X,40X(SL) & 100x(SL) Oil | ||
| Observation Head |
xxxxx | 30° inclined trinocular head, interpupillary distance adjustable : 52-75mm, diopter adjustable: +/-5 on R&L Oculars, 2 Position (0:100 & 50:50) |
| 30° Inclined Binocular Head, Interpupillary distance adjustable : 54-75mm, diopter adjustable: +/-5 on | xxxxx | |
| Nosepiece | Reversed Quintuple Nosepiece, Slot for POL/DIC | |
| Frame | Coaxial Coarse and Fine Focusing Control, with Upper Limit Stoper & Tension Control adjustment, range : 2mm, Fine Focus LC 0.002mm |
|
| Mechanical Stage | Refocusing type Rackless Mechanical Stage, Hard Ceramic Coated Surface, Double Slide Holder, Size(XY) 175×145mm, Travel (XY) 74×50mm, Vernier Markings : 0.1mm |
|
| Condenser | Abbe Condenser N.A. 1.25 (4X-100X) | |
| Transmitted Illumination | 100-240V built-in wideband voltage, 3W LED/6V30W illumination, intensity adjustable | |
| Fluorescent Illumination | xxxxx | |
Range Of Accessories
*Phase Contrast
*Darkfield
*Polarizing
*Fluorescence
*Dual Viewing Head
*Phase Contrast
*Darkfield
*Polarizing
*Fluorescence
*Dual Viewing Head
