| Model |
Pixels
|
Sensor Size
|
Pixel Size
|
Resolution/Frame Rate
(Live, Capture & Record)
|
Sensitivity
Dark Current
|
Exposure Time
|
Gain
|
| ProCAM HSB-2.3
|
2.3MP(Colour) |
1/1.2" |
5.86µm X 5.86µm |
1920x1200: 38FPS
960x600: 66FPS
Any Area ROI |
1120mv with 1/30s
0.5mv with 1/30s |
0.244ms~2s |
Upto 25X |
| ProCAM HSB-3.2C |
3.2MP (Colour) |
1/1.8" |
3.45µmX3.45µm |
2112x1584: 60FPS
1024x768: 85FPS
Any Area (ROI) |
1146mv with 1/30s
0.15mv with 1/30s |
0.1ms~15s
|
| ProCAM HSB-3.2M |
3.2MP (Mono) |
1/1.8" |
3.45µmX3.45µm |
2112x1584: 60FPS
1024x768: 85FPS
Any Area (ROI) |
1146mv with 1/30s
0.15mv with 1/30s |
0.1ms~15s |
| ProCAM HSB-3.5 |
3.5MP (Colour) |
1/1.2" |
2.64µm x 2.64µm |
2304x1536: 40FPS
1152x768: 40FPS
Any Area (ROI) |
3.0V/lux-sec |
25µs~2s |
| ProCAM HSB-5
|
5MP(Colour) |
1/1.8" |
2.775µmX2.775µm |
2592x1944:7FPS
1280x960:27FPS
640x480:90FPS
Any Area ROI |
0.53 V/lux-sec |
0.2ms~2000ms |
| ProCAM HSB-5A
|
5MP(Colour) |
1/1.8” |
2.2µm X 2.2µm |
2592x1944:30FPS
1224x1024:50FPS
Any Area ROI |
1146mv with1/30s
0.15mv with 1/30s |
0.2ms~2000ms |
| ProCAM HSB1-5
|
5MP(Colour) |
2/3” |
4.5µm X 4.5µm |
2448x2048:36FPS
1224x1024:50FPS
Any Area ROI |
1146mv with1/30s
0.15mv with 1/30s |
0.1ms~10min |
| ProCAM HSB-6
|
6.4MP(Colour) |
1/1.8" |
2.5µm X 2.5µm |
3088x2076:59FPS
2072x2072:60FPS
3088x2064:59FPS
1920x1080:60FPS
1544x1038:60FPS
1536x1024:59FPS
Any Area (ROI) |
425mv with 1/30s
0.15mv with 1/30s |
0.02ms~15s |
| ProCAM HSB-6A
|
6.3MP
(Colour/mono) |
1/1.8"
|
2.2µmX2.2µm |
3088x2064:59FPS
1920x1080:60FPS
1536x1024:59FPS
Any Area (ROI) |
425mv with 1/30s
0.15mv with 1/30s |
0.13ms~15s
(13µ sec to 15s) |
| ProCAM HSB-6B |
6.4MP(Colour) |
1/1.8" |
2.4µmX2.4µm |
3088x2076:59FPS
2072x2072:60FPS
3088x2064:59FPS
1920x1080:60FPS
1544x1038:60FPS
1536x1024:59FPS
Any Area (ROI) |
425mv with 1/30s
0.15mv with 1/30s |
13us-25us |
| ProCAM HSB-6M |
6.4MP(Mono) |
1/1.8" |
2.4µmX2.4µm |
3088x2076:59FPS
2072x2072:60FPS
3088x2064:59FPS
1920x1080:60FPS
1544x1038:60FPS
1536x1024:59FPS
Any Area (ROI) |
425mv with 1/30s
0.15mv with 1/30s |
0.02ms~15s |
| ProCAM HSB-8
|
8.3MP(Colour/Mono) |
1/1.8" |
2.4µm X 2.4µm |
3840x2160: 64FPS
1920x1080: 65FPS
Any Area (ROI) |
505mv with 1/30s
0.15mv with 1/30s |
0.02ms~15s |
1x to 251X |
| ProCAM HSB-8A |
8.0MP (Colour/Mono) |
1" (14.13mmX7.45mm) |
3.76µmX3.76µm |
3840x2160: 34FPS (HDMI 4K Resolution)
2048x1080: 64FPS
Any Area (ROI) |
1146mv with 1/30s
0.15mv with 1/30s |
0.1ms~15s |
Upto 25X |
| ProCAM HSB-10
|
10MP(Colour/mono) |
1/2.3" |
1.67µmX1.67µm |
3664x2748 7.2FPS
2560x1922:8FPS
2048x1534: 28FPS
1024X770: 53FPS
1912x686: 137FPS
Any Area (ROI) |
0.31v/lux-sec |
0.1ms~2000ms |
| ProCAM HSB-12
|
12MP(Colour) |
1" |
5µm X 5µm |
4096x3000:23.4FPS
2048x1500:46.3FPS
Any Area (ROI) |
1146mv with 1/30s
0.1mv with 1/30s |
0.244ms~15s |
| ProCAM HSB-12A |
12MP(Colour) |
1/1.8" |
2.4µm X 2.4µm |
3072x2048: 59FPS
1920x1080: 59FPS
1536x1024: 59FPS
640X480: 70FPS
Any Area (ROI) |
425mv with 1/30s
0.15mv with 1/30s |
0.02ms~30s |
| ProCAM HSB-12B |
12MP(Colour) |
1" |
3.45µm X 3.45µm |
4096x3000:32FPS
2048x1500:64FPS
Any Area (ROI) |
1146mv with 1/30s
0.1mv with 1/30s |
27µs~15s |
| ProCAM HSB-16
|
16MP
(Colour/mono) |
1/2.33" |
1.4µmX1.4µm |
4648x3506: 10FPS
2304x1750: 15.0FPS
1536x1168: 28 FPS
Any Area (ROI) |
0.53 V/lux-sec |
100µ-30s |
| ProCAM HSB-18
|
18MP
(Colour/mono) |
1/2.3"
(6.14mm x 4.61mm) |
1.44µmX1.44µm |
4912x3684: 5.6FPS
2456x1842: 18.1FPS
1920x1080: 31FPS
1228x922: 32.2FPS
Any Area (ROI) |
0.62 V/lux-sec |
10µs~2 Sec |
| ProCAM HSB-20
|
20MP
(Colour/mono) |
1" |
3.45µm X 3.45µm |
5472x3648:15FPS
2736x1824:53FPS
1824x1216:67FPS
Any Area (ROI) |
462mv with 1/30s
0.21mv with 1/30s |
39µs-60s |
| ProCAM HSB-21
|
21MP
(Colour) |
1/1.2" |
5.86µm X 5.86µm |
5280x3954: 17FPS
3952x3952: 17FPS
2640x1976: 56FPS
1760x1316: 67FPS
584x438: 192FPS
Any Area (ROI) |
399mv with 1/30s
0.1mv with 1/30s |
0.1ms~15s |
Dynamic Range
SN Ratio |
75dB
35.5dB |
| Image Data Format |
10/12/14 bit (multiply 3 for RGB) |
| AD Conversion |
10/12/14 bit (multiply 3 for RGB) |
| Binning |
1x1, 2x2, 3x3, 4x4 |
| Capture/Control API |
Native C/C++, C#/VB.NET, Directshow, Twain, Labview |
| Cooling |
Natural/Peltier fan cooling (optional)
Temperature stable @ 25°C for ambient temperature between 18°C-31°C |
| Spectral Range(nm) |
380nm ~ 720nm (with infrared filter) |
| Shutter |
Electronic rolling shutter(Global shutter optional) |
| Operating Mode |
Continuous output |
| Scanning Mode |
Progressive Scan |
| Exposure Control |
Manual/Auto/Area |
| White Balance |
Manual/One time/Auto/Area |
| Image Processing |
GAMMA/Contrast/Black Level/Noise Reduction/3D Noise Reduction/Sharpness/Saturation |
| Quantum Efficiency |
70% |
| Picture Format |
JPEG/BMP/PNG/RAW |
| Colour rendering technique |
Ultra fine colour engine |
| Software interface |
Radical ProCAM Software |
| Operating System |
Windows 7/8/10/11 (32 & 64 bit) OS X (Mac OS X), Linux |
| Data Interface |
USB3.0/3.1 (B Type), with 2.5 cable, LV-TV Tube adopter, image capture button on microscope body or though single mouse click |
| Lens Mount |
0.5X C/CS Mount/1x lens, Compatible C-Mount with microscope & sizing adapter tube |
| Technology |
On-sensor light guide technology for reducing scattering of light inside the senor |
| Dimensions/Weight |
Metallic square body 58mm, height 36mm/(Exclude Lens Mount)/Approx. 180g |
| Rated Volt/Power |
5V via USB |
| Temp./Humidity |
Operation: -10~60°C /storage: -20°C ~ 70°C/ Working: 10%~90% RH (No Condensation), 45-85% humidity, 10% ~ 60% |
