Medical Research Microscopes Research Upgrade & Accessories Optics

Optics



Radical infinity optical system consisting of objectives for any demanding application. Lenses guarantee the quality, flexibility and performance. The new generation universal infinity optical system is corrected for colour & spherical aberrations. The Parfocal & Precentered objectives are antifungal and anti-mould treated for longer life. The multilayer coating also helps to enhance the life of optical system

Compatible with Radical Clinical & Research Microscopes
Infinity Achromat Objective RIAO-04 Achromat 4X, N.A. 0.1, W.D. 30mm
  RIAO-10 Achromat 10X, N.A. 0.25, W.D. 7mm
  RIAO-20 Achromat 20X, N.A. 0.4, W.D. 3.9mm (long working distance)
  RIAO-40 Achromat 40X, N.A. 0.65, W.D. 0.65mm (long working distance)
  RIAO-60 Achromat 60X, N.A. 0.8, W.D. 0.3mm, spring loaded
  RIAO-100 Achromat 100X, N.A. 0.36-1.25, W.D. 0.23mm, oil, spring loaded
  RIAO-100ir Achromat 100X, N.A. 0.5-1.25, W.D. 0.23mm, oil, spring loaded with iris

Objectives RXIPO1.25C POL PL1.25X, N.A. 0.04, W.D. 3.9mm, plan achromatic, infinite, with cover glass corrected
RXIPO2.5C POL PL2.5X, N.A. 0.07, W.D. 11.2mm, plan achromatic, infinite, with cover glass corrected
RXIPO2.5P POL PL2.5X, N.A. 0.07, W.D. 11.2mm, plan achromatic, infinite, unbreakable container for storage
RXIPO4 4X, N.A 0.10, W.D 15.5mm, plan achromatic, infinite, unbreakable container for storage
RXIPO4i 4X, N.A 0.10, W.D 17.2mm, plan achromatic, infinite, unbreakable container for storage
RXIPO5C POL PL5X, N.A. 015, W.D. 12.0mm, plan achromatic, infinite, with cover glass corrected
RXIPO10 10X, N.A 0.25, W.D 7mm, plan achromatic, infinite, unbreakable container for storage
RXIPO10a 10X, N.A 0.25, W.D. 10.6mm, plan achromatic, infinite, unbreakable container for storage
RXIPO10lw 10X, N.A 0.25, W.D 21mm, plan achromatic, infinite, unbreakable container for storage
RXIPO20lw 20X, N.A 0.4, W.D 6.7mm, plan achromatic, infinite, unbreakable container for storage
RXIPO20lcg 20X, N.A 0.4, W.D 6.7mm, plan achromatic, infinite, cover glass correction 0.17mm
RXIPO40 40X, N.A 0.65, W.D 0.7mm, plan achromatic, infinite, spring loaded, unbreakable container for storage
RXIPO40i 40X, N.A 0.65, W.D 0.6mm, plan achromatic, infinite, spring loaded, unbreakable container for storage
RXIPO40-CC 40X, N.A 0.65, W.D 2.6mm, plan achromatic, infinite, over glass 1.2mm, unbreakable container for storage
RXIPO65 65X, N.A 0.80, W.D. 0.3mm, plan achromatic, infinite, spring loaded, unbreakable container for storage
RXIPO100 100X, N.A 1.25, W.D 0.18mm, plan achromatic, oil immered, infinite, spring loaded, unbreakable container for storage
RXIPO100a 100X, N.A 1.25, W.D 0.13mm, plan achromatic, oil immered, spring loaded, spring loaded, unbreakable container for storage

Infinity Plan Achromat Objective RIPAO-01 Plan Achromat 1X, N.A. 0.04, W.D. 3.2mm, infinite
  RIPAO-02 Plan Achromat 2X, N.A. 0.06, W.D. 7.5mm, infinite
  RIPAO-04 Plan Achromat 4X, N.A. 0.10, W.D. 30mm, infinite
  RIPAO-04i Plan Achromat 4X, N.A. 0.10, W.D. 30.7mm, infinite
  RIPAO-10 Plan Achromat 10X, N.A. 0.25, W.D. 11mm, infinite
  RIPAO-10i Plan Achromat 10X, N.A. 0.25, W.D. 17.4mm, infinite
  RIPAO-10ewd Plan Achromat 10X, N.A. 0.25, W.D. 12mm, infinite
  RIPAO-20 Plan Achromat 20X, N.A. 0.4, W.D. 1.2mm, infinite, spring loaded
  RIPAO-20elw Plan Achromat 20X, N.A. 0.4, W.D. 10.6mm, infinite
  RIPAO-40 Plan Achromat 40X, N.A. 0.65, W.D. 0.65mm, infinite, spring loaded
  RIPAO-40i Plan Achromat 40X, N.A. 0.65, W.D. 0.65mm, infinite, spring loaded
  RIPAO-40cg Plan Achromat 40X, N.A. 0.65, W.D. 0.36mm, infinite, spring loaded, cover glass correction 0.17mm
  RIPAO-40ewd 40X, N.A 0.65, W.D 36mm, plan achromatic, infinite
  RIPAO-40ncg Plan Achromat 40X, N.A. 0.65, W.D. 0.48mm, infinite, No cover glass, spring loaded
  RIPAO-50 Plan Achromat 50X, N.A. 0.9, W.D. 0.35mm, infinite, spring loaded, oil
  RIPAO-60 Plan Achromat 60X, N.A. 0.8, W.D. 0.3mm, infinite, spring loaded, dry
  RIPAO-60D Plan Achromat 60X, N.A 0.80, W.D 0.30mm, dry, infinite, spring loaded, unbreakable container for storage
  RIPAO-60i Plan Achromat 60X, N.A. 0.5-1.25, W.D. 0.20mm, spring loaded, oil, iris diaphragm, unbreakable container for storage
  RIPAO-60cg Plan Achromat 60X, N.A. 0.8, W.D. 0.3mm, infinite, spring loaded, cover glass correction 0.17mm
  RIPAO-100 Plan Achromat 100X, N.A. 1.25, W.D 0.30mm, infinite, spring loaded, oil immersed.
  RIPAO-100cg Plan Achromat 100X, N.A. 1.25, W.D 0.10mm, infinite, spring loaded, oil, cover glass correction 0.17mm
  RIPAO-100ewd Plan Achromat 100X, N.A. 1.25, W.D 0.36mm, spring loaded, oil.
  RIPAO-100ncg Plan Achromat 100X, N.A. 0.9, W.D 0.26mm, infinite, No cover glass, spring loaded

Infinity Plan SAPO/Fluor Objective RIPFO-2.5 Plan Fluor 2.5X, N.A. 0.08, W.D. 10.7mm, suitable for BF, POL, DIC
  RIPFO-04 Plan Fluor/S-APO 4X, N.A. 0.13, W.D. 17.1mm
  RIPFO-04i Plan Fluor/S-APO 4X, N.A 0.10, infinite
  RIPFO-10 Plan Fluor 10X, N.A. 0.3, W.D. 16.0mm
  RIPFO-10i Plan Fluor 10X, N.A 0.25, infinite
  RIPFO-20 Plan Fluor 20X, N.A. 0.5, W.D. 2.1mm
  RIPFO-20B Plan Fluor 20X, N.A. 0.5, W.D. 2.1mm
  RIPFO-20elwd Plan Fluor 20X, N.A. 0.45, W.D. 8.1-7.0mm, Extra long working distance
  RIPFO-20elwd-cc ELWD Plan Fluor 20X, N.A. 0.45, W.D. 8.2, with cover glass correction 0-2.0mm
  RIPFO-40 Plan Fluor/SAPO 40X, N.A. 0.75, W.D. 0.72mm, spring loaded
  RIPFO-40i Plan Fluor/SAPO 40X, N.A 0.65, W.D 0.66mm, infinite spring loaded
  RIPFO-40ic Plan Fluor 40X, N.A. 0.6, W.D. 4-2.7mm, Extra Long working distance
  RIPFO-40oil Plan Fluor 40X, N.A. 1.3, W.D. 0.2mm, oil, spring loaded
  RIPFO-40elwd Plan Fluor 40X, N.A. 0.6, W.D. 3.7-2.7mm, Extra Long working distance
  RIPFO-40elwd-CC Plan Fluor 40X, N.A. 0.6, W.D. 3.5-2.8mm, Extra Long working distance with cover glass correction 0-2mm
  RIPFO-50oil Plan Fluor 50X, N.A. 0.85, W.D. 0.30mm, spring loaded oil
  RIPFO-60 Plan SAPO/Fluor 60X, N.A. 0.95, W.D. 0.3mm, spring loaded
  RIPFO-60cc Plan Fluor/SAPO 60X, N.A. 0.85, W.D. 2.2-1.5mm, having correction collar
  RIPFO-60Dry Plan S-APO/Fluor 60X, N.A. 0.9, W.D.0.2mm, dry, correction collar
  RIPFO-60oil Plan Fluor 60X, N.A. 0.5-1.25, W.D. 0.22mm, oil, spring loaded with iris
  RIPFO-60elwd Plan Fluor 60X, N.A. 0.70, W.D. 2.1-1.5mm, Extra Long working distance
  RIPFO-63oil Plan Fluor/SAPO 63X, N.A. 1.3, W.D. 0.28mm, oil, spring loaded with iris, unbreakable container for storage
  RIPFO-100dry Plan Fluor 100X, N.A. 0.9, W.D. 0.3mm, dry, spring loaded
  RIPFO-100 Plan Fluor/SAPO 100X, N.A. 1.3, W.D. 0.25mm, oil, spring loaded, infinite
  RIPFO-100i Plan Fluor/SAPO 100X, N.A 1.25, W.D 0.16mm, infinite, oil immersed, spring loaded
  RIPFO-100ir Plan Fluor 100X, N.A. 0.5-1.3, W.D. 0.2mm, oil, spring loaded with iris
  RIPFO-05PL 5X, N.A. 0.13, W.D. 11.8mm, plan S-APO
  RIPFO-10PL 10X, N.A. 0.25 W.D. 17mm, plan S-APO
  RIPFO-20PL 20X, N.A. 0.35 W.D. 6.9mm, plan S-APO, long working distance
  RIPFO-40PL 40X, N.A. 0.55 W.D. 3.7mm, plan S-APO, having correction collar, long working distance
  RIPFO-100PL LWD 100X, N.A. 1.25, W.D. 0.28mm, plan S-APO, oil immersed, spring loaded

Infinity Plan Apochromat Objective RIAPAO-1.0 Plan Apochromat Fluor 1X, N.A. 0.04, W.D. 5.0mm
  RIAPAO-1.0 Plan Apochromat Fluor 1.5X, N.A. 0.05, W.D. 4.2mm
  RIAPAO-1.25 Plan Apochromat Fluor 1.25X, N.A. 0.05, W.D. 4.2mm
  RIAPAO-02 Plan Apochromat Fluor 2X, N.A. 0.1, W.D. 8.5mm
  RIAPAO-02a Plan Apochromat/Fluor 2X, N.A. 0.08, W.D. 6.2mm
  RIAPAO-2.5 Plan Apochromat Fluor 2.5X, N.A. 0.06, W.D. 7.5mm
  RIAPAO-04 Plan Apochromat Fluor 4X, N.A. 0.2, W.D. 20mm
  RIAPAO-04a Plan Apochromat Fluor 4X, N.A. 0.16, W.D. 13.0mm
  RIAPAO-04L Plan Apochromat/Fluor 4X, N.A. 0.10, W.D. 30mm
  RIAPAO-05 Plan Apochromat Fluor 5X, N.A. 0.12, W.D. 14mm,
  RIAPAO-10 Plan Apochromat Fluor 10X, N.A. 0.45, W.D. 4.0mm
  RIAPAO-10a Plan Apochromat Fluor 10X, N.A. 0.4, W.D. 3.1mm
  RIAPAO-10B Plan Apochromat Fluor 10X, N.A. 0.45, W.D. 4.2mm
  RIAPAO-10L Plan Apochromat/Fluor 10X, N.A. 0.25, W.D. 10.6mm
  RIAPAO-20 Plan Apochromat Fluor 20X, N.A. 0.80, W.D. 1.0mm, spring loaded
  RIAPAO-20a Plan Apochromat Fluor 20X, N.A. 0.80, W.D. 0.6mm, spring loaded
  RIAPAO-20d Plan Apochromat Fluor 20X, N.A. 0.80, W.D. 1.0mm, dry, spring loaded.
  RIAPAO-20i Plan Apochromat Fluor 20X, N.A. 0.75, W.D. 1mm, spring loaded
  RIAPAO-20L Plan Apochromat/Fluor 20X, N.A 0.45, W.D 2.1mm, spring loaded
  RIAPAO-20L-CC Plan Apochromat Fluor 20X, N.A 0.45, W.D 8.2-6.9mm, spring loaded
  RIAPAO-40 Plan Apochromat Fluor 40X, N.A. 0.95, W.D. 0.14mm, spring loaded
  RIAPAO-40a Plan Apochromat Fluor 40X, N.A. 0.95, W.D. 0.18mm, spring loaded
  RIAPAO-40B Plan Apochromat Fluor 40X, N.A. 0.95, W.D. 0.25mm
  RIAPAO-40acc Plan Apochromat Fluor 40X, N.A. 0.95, W.D. 0.18mm, spring loaded with correction collar 0.11-0.23mm
  RIAPAO-40d Plan Apochromat Fluor 40X, N.A. 1.4, W.D. 0.14mm, dry, spring loaded
  RIAPAO-40k Plan Apochromat/Fluor 40X, N.A. 0.75, W.D. 0.65mm, spring loaded
  RIAPAO-40L Plan Apochromat/Fluor 40X, N.A. 0.65, W.D. 0.65mm, spring loaded
  RIAPAO-40L-CC Plan Apochromat Fluor 40X, N.A. 0.6, W.D. 3.6-2.8mm, spring loaded.
  RIAPAO-40CC Plan Apochromat Fluor 40X, N.A. 0.95, W.D. 0.21mm, spring loaded with correction ring
  RIAPAO-40oil Plan Apochromat Fluor 40X, N.A. 1.0, W.D. 0.16mm, oil, spring loaded
  RIAPAO-60 Plan Apochromat Fluor 60X, N.A. 0.95, W.D. 0.15mm, spring loaded
  RIAPAO-60acc Plan Apochromat Fluor 60X, N.A. 0.9, W.D. 0.2, spring loaded, dry, correction collar
  RIAPAO-60CC Plan Apochromat Fluor 60X, N.A. 0.95, W.D. 0.21-0.11, spring loaded, Dry, Corretion ring
  RIAPAO-60W Plan Apochromat Fluor 60X, N.A. 1.4, W.D. 0.22mm, water immerstion, spring loaded
  RIAPAO-60oil Plan Apochromat Fluor 60x, N.A. 1.42, W.D. 0.17mm, oil, spring loaded
  RIAPAO-60oilcc Plan Apochromat Fluor 60x, N.A. 1.42, W.D. 0.17mm, oil, spring loaded, correction collar
  RIAPAO-63 Plan Apochromat Fluor 60X, N.A. 0.80, W.D. 0.4mm, spring loaded
  RIAPAO-100 Plan Apochromat Fluor 100X, N.A. 1.45, W.D. 0.13mm, oil, spring loaded
  RIAPAO-100e Plan Apochromat Fluor 100X, N.A. 1.40, W.D. 0.13mm, oil, spring loaded
  RIAPAO-100B Plan Apochromat Fluor 100X, N.A. 1.45, W.D. 0.14mm, oil, spring loaded
  RIAPAO-100L Plan Apochromat/Fluor 100X, N.A. 1.25, W.D. 0.29mm, oil, spring loaded
  RIAPAO-100cr Plan Apochromat Fluor 100X, N.A. 1.4, W.D. 0.13mm, oil, spring loaded, correction collar /ring
  RIAPAO-100ncg Plan Apochromat Fluor 100X, N.A. 1.4, W.D. 0.17mm, No cover glass oil

Infinity Super Fluor Objective RISFO-04 Super Fluor 4x, N.A. 0.2, W.D. 15.5mm
  RISFO-10 Super Fluor 10x, N.A. 0.5, W.D. 1.2mm, spring loaded
  RISFO-20 Super Fluor 20x, N.A. 0.75, W.D. 1mm, spring loaded
  RISFO-40 Super Fluor 40x, N.A. 0.9, W.D. 0.3mm, spring loaded
  RISFO-40oil Super Fluor 40x, N.A. 1.3, W.D. 0.22mm, oil, spring loaded
  RISFO-100 Super Fluor 100x, N.A. 0.5 - 1.30, W.D. 0.2mm, oil, spring loaded with iris

Infinity water dipping Objective RIWDO-10W Fluor 10X water, N.A. 0.3, W.D. 2mm
  RIWDO-20W Fluor 20X water, N.A. 0.5, W.D. 2mm
  RIWDO-40W Fluor 40X water, N.A. 0.8, W.D. 2mm
  RIWDO-60W Fluor 60X water, N.A. 1, W.D. 2mm

Infinity Achromat Phase Contrast RIAPC-10 LWD Achromat phase infinity 10x, N.A. 0.25, W.D. 7mm
  RIAPC-10i LWD Achromat phase infinity 10x, N.A. 0.30, W.D. 15mm
  RIAPC-20 LWD Achromat phase infinity 20x, N.A. 0.4, W.D. 3.9mm
  RIAPC-20i LWD Plan achromat phase 20X N.A. 0.45, W.D. 8.2-6.9mm
  RIAPC-20il LWD Achromat phase infinity 20x, N.A. 0.40, W.D. 1.20mm
  RIAPC-40 LWD Achromat phase infinity 40x, N.A. 0.65, W.D. 0.65mm, spring loaded
  RIAPC-40i LWD Achromat phase infinity 40x, N.A. 0.65, W.D. 0.56mm, spring loaded
  RIAPC-40iCC LWD Plan achromat phase 40X N.A. 0.60, W.D. 3.6-2.8mm, spring loaded, with cover glass correction 0-2.0mm
  RIAPC-100 LWD Achromat phase infinity 100x, N.A. 1.25, W.D. 0.23mm, oil, spring loaded

Infinity phase Contrast RIPAPC-05 Plan fluor achromat phase 5x, N.A. 0.15, W.D. 12mm
  RIPAPC-10 Plan fluor achromat phase 10x, N.A. 0.25, W.D. 11.5mm
  RIPAPC-20 Plan fluor achromat phase 20x, N.A. 0.4, W.D. 1.2mm
  RIPAPC-20CC Plan fluor achromat phase 20X N.A. 0.45, W.D. 8.2-6.9mm
  RIPAPC-20lwd Plan fluor achromat phase 20x, N.A. 0.45, W.D. 8.2mm
  RIPAPC-40 Plan fluor achromat phase 40x, N.A. 0.75, W.D. 2.1mm, spring loaded
  RIPAPC-40CC Plan fluor achromat phase 40X N.A. 0.6, W.D. 3.6-2.8mm, spring loaded, with cover glass correction 0-2.0mm
  RIPAPC-40cg Plan fluor achromat phase 40x, N.A. 0.55, W.D. 2.7-1.7mm with cover glass, spring loaded
  RIPAPC-40lwd Plan fluor achromat phase 40x, N.A. 0.6, W.D. 3.7mm, spring loaded
  RIPAPC-60CC Plan fluor achromat 60X N.A. 0.70, W.D. 2.6-1.8mm, spring loaded
  RIPAPC-63 Plan fluor achromat 63X N.A. 0.95, W.D. 0.28mm, spring loaded
  RIPAPC-100 Plan fluor achromat phase 100x, N.A. 1.25, W.D. 0.30mm, oil, spring loaded
RIPAPC1-05 Plan achromat phase 5x, N.A. 0.15, W.D. 12mm
  RIPAPC1-10 Plan achromat phase 10x, N.A. 0.25, W.D. 11.5mm
  RIPAPC1-10c Plan achromat phase 10x, N.A. 0.25, W.D. 10mm
  RIPAPC1-20 Plan achromat phase 20x, N.A. 0.4, W.D. 1.2mm
  RIPAPC1-20i Plan achromat phase 20x, N.A. 0.50, W.D. 1.2mm
  RIPAPC1-20CC Plan achromat phase 20X N.A. 0.45, W.D. 8.2-6.9mm
  RIPAPC1-20CC2 Plan achromat phase 20x, N.A. 0.4, W.D. 3.7-2.4mm with correction ring
  RIPAPC1-20lwd Plan achromat phase 20x, N.A. 0.45, W.D. 8.2mm
  RIPAPC1-40 Plan achromat phase 40x, N.A. 0.65, W.D. 2.1mm, spring loaded
  RIPAPC1-40a Plan achromat phase 40x, N.A. 0.65, W.D. 0.5mm, spring loaded
  RIPAPC1-40i Plan achromat phase 40x, N.A. 0.75, W.D. 2.1mm, spring loaded
  RIPAPC1-40CC Plan achromat phase 40X N.A. 0.6, W.D. 3.6-2.8mm, spring loaded, with cover glass correction 0-2.0mm
  RIPAPC1-40cg Plan achromat phase 40x, N.A. 0.55, W.D. 2.7-1.7mm with cover glass, spring loaded
  RIPAPC1-40lwd Plan achromat phase 40x, N.A. 0.6, W.D. 3.7mm, spring loaded
  RIPAPC1-40ilwd LWD Plan achromat phase 40x, N.A. 0.40, W.D. 3.1mm, spring loaded
  RIPAPC1-60CC Plan achromat 60X N.A. 0.70, W.D. 2.6-1.8mm, spring loaded
  RIPAPC1-60lwd LWD Plan achromat 60X N.A. 0.55, W.D. 2.1mm, spring loaded
  RIPAPC1-100 Plan achromat phase 100x, N.A. 1.25, W.D. 0.2mm, oil, spring loaded
  RIPAPC1-100d Plan achromat phase 100x, N.A. 1.25, W.D. 0.15-0.2mm, spring loaded & cover glass thickness
  RIPAPC2-10 Plan achromat phase 10x, N.A. 0.3, W.D. 17mm
  RIPAPC2-20 Plan achromat phase 20x, N.A. 0.5, W.D. 6.5mm
  RIPAPC2-40 Plan achromat phase 40X N.A. 0.75, W.D.2mm, spring loaded
  RIPAPC2-40is Plan achromat phase 40X N.A. 0.60, W.D.2mm, spring loaded, correction collor cover glass 0-2mm

Infinity Plan S-APO/Fluor Phase Contrast RIPFPC-04 Plan fluor/S-APO phase 4x, N.A. 0.13, W.D. 16.4mm
RIPFPC-04i Plan fluor/S-APO phase 4x, N.A. 0.13, W.D. 17mm
  RIPFPC-10 Plan fluor/SAPO phase 10x, N.A. 0.3, W.D. 16mm
  RIPFPC-10i Plan fluor/SAPO phase 10x, N.A. 0.25 W.D. 18mm
  RIPFPC-10ie Plan fluor/SAPO phase 10x, N.A. 0.3, W.D. 10mm
  RIPFPC-20 Plan fluor/SAPO phase 20x, N.A. 0.5, W.D. 2.2mm
  RIPFPC-20B Plan fluor/S-APO phase 20x, N.A. 0.45, W.D. 3.2mm
  RIPFPC-20C Plan fluor/SAPO phase 20x, N.A. 0.45, W.D. 8mm, elwd
  RIPFPC-20lwd Plan fluor/SAPO phase 20x, N.A. 0.45, W.D. 6.5-7.8mm
  RIPFPC-20elwd Plan fluor phase 20x, N.A. 0.45, W.D. 8.1-7.0mm, extra long working distance, with correction ring
  RIPFPC-20elwdi Plan fluor phase 20x, N.A. 0.45, W.D. 8.2-6.9mm, extra long working distance
  RIPFPC-40 Plan fluor/SAPO phase 40x, N.A. 0.80, W.D. 0.72mm, spring loaded
  RIPFPC-40a Plan fluor/SAPO phase 40x, N.A. 0.75, W.D. 0.51mm, spring loaded
  RIPFPC-40e Plan fluor/SAPO phase 40x, N.A. 0.75, W.D. 0.72mm, spring loaded
  RIPFPC-40FP Plan fluor phase/S-APO 40x, N.A. 0.65, W.D. 3.7mm, spring loaded
  RIPFPC-40elwd Plan fluor/SAPO phase 40x, N.A. 0.6, W.D. 3.7-2.7mm, spring loaded, extra long working distance, with correction ring
  RIPFPC-40elwdi Plan fluor/SAPO phase 40x, N.A. 0.6, W.D. 2.0, 4mm, spring loaded, extra long working distance, with correction ring/collar.
  RIPFPC-40elwd3 Plan fluor phase 40x, N.A. 0.6, W.D. 3-5-2.8mm, spring loaded, extra long working distance with cover glass correction 0-2mm
  RIPFPC-40elwd4 Plan fluor/S-APO phase 40x, N.A. 0.6, W.D. 3-4.2mm, spring loaded, extra long working distance with cover glass correction 0-2mm
  RIPFPC-40elwd5 Plan fluor phase 40x, N.A. 0.60, W.D. 3.6-2.8mm, spring loaded, extra long working distance, with correction ring
  RIPFPC-40elwd6 Plan fluor phase 40x, N.A. 0.6, W.D. 2.7-4mm, spring loaded, extra long working distance
  RIPFPC-60 Plan fluor phase 60x, N.A. 0.7, W.D. 2.1-1.5mm
  RIPFPC-60i Plan fluor phase 60x, N.A. 0.7, W.D. 1.5-22mm with correction color
  RIPFPC-60elwd Plan fluor phase 60x, N.A. 0.70, W.D. 2.6-1.8mm, spring loaded, extra long working distance
  RIPFPC-63 LWD Plan fluor phase 63x, N.A. 0.75, W.D. 1.7mm
  RIPFPC-63e LWD Plan S-APO phase 63x, N.A. 0.70, W.D. 1.7mm
  RIPFPC-63cc LWD Plan fluor phase 63x, N.A. 0.75, W.D. 1.7mm with correction ring 0-1.5mm
  RIPFPC-100 Plan fluor/SAPO phase 100x, N.A. 1.3, W.D. 0.2mm, oil, spring loaded

Infinity Plan APO RIPAPPC-04 Plan Apochromat 4X, N.A. 0.13, W.D. 30mm
RIPAPPC-10L Plan apochromat 10x, N.A. 0.45, W.D. 6.5mm, infinite
  RIPAPPC-20L Plan apochromat 20x, N.A. 0.80, W.D 0.65mm, infinite, spring loaded
  RIPAPPC-40L Plan apochromat 40x, N.A. 0.65, W.D 0.60mm, infinite, spring loaded
  RIPAPPC-60 Plan apochromat 63x, N.A. 1.4, W.D 0.13mm, infinite, oil, spring loaded
  RIPAPPC-63L Plan apochromat 63x, N.A. 0.95, W.D 0.17mm, infinite, spring loaded
  RIPAPPC-100L Plan apochromat 100x, N.A. 1.35, W.D. 0.29mm, infinite, oil, spring loaded

Infinity Plan APO Phase RIPAPPC-10 LWD Plan apochromat phase 10x, N.A. 0.4, W.D. 6.5mm, infinite
RIPAPPC-10PH LWD Plan apochromat phase 10x, N.A. 0.45, W.D. 6.5mm, infinite
  RIPAPPC-20PH Plan apochromat phase 20x, N.A. 0.75, W.D 0.65mm, infinite, spring loaded
  RIPAPPC-20Phi Plan apochromat phase 20x, N.A. 0.50, W.D 1.1mm, infinite, spring loaded
  RIPAPPC-40PH LWD Plan apochromat phase 40x, N.A. 0.75, W.D 0.60mm, infinite, spring loaded
  RIPAPPC-40PHi LWD Plan apochromat phase 40x, N.A. 1.15, W.D 0.61mm, infinite, spring loaded
  RIPAPPC-63PH Plan apochromat phase 63x, N.A. 0.95, W.D 0.17mm, infinite, spring loaded
  RIPAPPC-100PH Plan apochromat phase 100x, N.A. 1.35, W.D. 0.29mm, infinite, oil, spring loaded

Infinity Plan Apochromat Phase Contrast RIPAPPC-10c Plan apochromat phase 10x, N.A. 0.30, W.D. 6.5mm, infinite
RIPAPPC-20 Plan apochromat phase 20x, N.A. 0.75, W.D. 1mm, infinite, spring loaded
  RIPAPPC-40 Plan apochromat phase 40x, N.A. 0.95, W.D. 0.21mm, infinite, spring loaded
  RIPAPPC-40oil Plan apochromat phase 40x, N.A. 1.0, W.D. 0.16mm, infinite, oil, spring loaded
  RIPAPPC-60D Plan apochromat phase 60x, N.A. 0.95, W.D. 0.15mm, infinite, spring loaded
  RIPAPPC-60oil Plan apochromat phase 60x, N.A. 1.4, W.D. 0.13mm, infinite, oil, spring loaded
  RIPAPPC-60D-CC Plan apochromat phase 60x, N.A. 0.70, W.D. 1.5mm, dry, spring loaded, infinite, having correction collar for cover glass thickness correction from 0.1- 1.3mm
  RIPAPPC-63i-CC Plan apochromat phase 63x, N.A. 0.70, W.D. 1.8-2.6mm, spring loaded, infinite, having correction collar for cover glass thickness correction from 0.1- 1.3mm
  RIPAPPC-100 Plan apochromat phase 100x, N.A. 1.45, W.D. 0.13mm, infinite, oil, spring loaded
  RIPAPPC-100c Plan apochromat phase 100x, N.A. 1.40, W.D. 0.13mm, infinite, oil, spring loaded

Lambda APO objectives RIAPAOLD-2 Plan Apochromat L.W. 2x, N.A. 0.10, W.D. 8.5mm
  RIAPAOLD-4 Plan Apochromat L.W. 4x, N.A. 0.20, W.D. 20.0mm
  RIAPAOLD-10 Plan Apochromat L.W. 10x, N.A. 0.45, W.D. 4.0mm
  RIAPAOLD-20 Plan Apochromat L.W. 20x, N.A. 0.80, W.D. 0.80mm, spring loaded
  RIAPAOLD-40 Plan Apochromat L.W. 40x, N.A. 0.95, W.D. 0.21mm, spring loaded
  RIAPAOLD-60 Plan Apochromat L.W. 60x, N.A. 1.42, W.D. 0.15mm, oil, spring loaded for FOV 25mm
  RIAPAOLD-100 Plan Apochromat L.W. 100x, N.A. 1.45, W.D. 0.13mm, oil, spring loaded

Infinity Hoffman Modulation Contrast RIHMC-10 Hoffman modulation contrast 10x, N.A. 0.25, W.D. 6.2mm
  RIHMC-20 Hoffman modulation contrast 20x, N.A. 0.40, W.D. 3.1mm, long working distance
  RIHMC-40 Hoffman modulation contrast 40x, N.A. 0.55, W.D. 2.7-1.7mm, long working distance

Objectives for RSMr RSMR10OC1.0 Plan achromat parfocal objective 1x (WD 63mm)
RSMR10OC1.5 Plan achromat parfocal objective 1.5x (WD 28mm)
RSMR10OC0.63 Plan achromat parfocal objective 0.63x (WD 107mm)
Plan Achromat
Magnification Resolution
4x 2.8µm
10x 1.10µm
20x 0.69µm
40x 0.42µm
60x 0.37µm
100x 0.22µm
Plan Fluorite
Magnification Resolution
4x 2.12µm
10x 0.92µm
20x 0.55µm
40x 0.37µm
60x 0.32µm
100x 0.21µm
Plan Apochromat
Magnification Resolution
4x 1.375µm
10x 0.61µm
20x 0.37µm
40x 0.29µm
60x 0.29µm
100x 0.20µm

As we are continuously improving & developing our products, this websites may not be updated with advancements done. However, we try our best to update the website for latest information's
For complete updated specifications, please do ask for latest brochures

Educational Microscopes

Laboratory Clinical Microscopes

Medical Research Microscopes

Microscope Cameras

Industrial Microscopes

Advanced Microscopy System

Camera Control Software

Material Science Software

Life Sciences Software

Infrared Thermography

Metrology & Metallurgy

About Radical

Support

Contact Info
